DN6-2D Series
Intelligent Dual-Head Cutting Machine
Two heads cutting the same pattern simultaneously — double the productivity.
The intelligent dual-head cutting machine lets two heads cut the same shape at the same time — doubling output. Especially valuable for textiles, foaming and composite materials. No dies or paper patterns required, freeing designers to iterate faster.
- Dual synchronous cutting heads
- 2× productivity for symmetric jobs
- Ideal for textile, foam & composite
- No dies — pure digital workflow
Technical Data
Full specifications.
Every AgileBull machine ships with a modular tooling head, servo-driven precision axes and dual-layer safety systems.
- Effective Cutting Area (L×W)
- 2500×1600 / 2500×1800 / 3000×2000 mm (customisable)
- Cutting Tools
- Dual vibration knives, trailing knife, half-cut, pneumatic knife, press wheel, V-slot knife
- Safety Devices
- Physical anti-collision + infrared sensing + smart head-to-head avoidance
- Cutting Thickness
- 0.2 – 60 mm (customisable)
- Cutting Speed
- ≤ 1200 mm/s
- Cutting Accuracy
- ±0.1 mm
- Repeatability
- ≤ 0.05 mm
- Min. Cutting Diameter
- ≥ 3 mm
- Positioning
- Laser light or CCD camera positioning
- Material Fixing
- Vacuum suction
- Transmission Interface
- Ethernet port
- Software Compatibility
- AI, CAD, CorelDRAW & all box-type design software
- Command System
- DXF, HPGL compatible
- Control Panel
- Multilingual LCD touch panel
- Power Supply
- AC 220V / 380V ±10%, 50Hz — 9 kW total
- Air Pump
- 7.5 kW
- Operating Environment
- -10°C – 40°C, 20 – 80% RH
