DN6-2H Series
Intelligent Double-Beam Cutting Machine
Asynchronous dual-beam system — footprint of one machine, output of two.
A dual-beam asynchronous cutting system with intelligent avoidance and hardware anti-collision. Advanced rolling table design allows customisable platform width and theoretically unlimited cutting length. Vacuum suction platform delivers ultra-strong, powerful hold-down.
- Two independent asynchronous beams
- Rolling table — unlimited length
- Smart avoidance + anti-collision
- Powerful vacuum suction hold-down
Technical Data
Full specifications.
Every AgileBull machine ships with a modular tooling head, servo-driven precision axes and dual-layer safety systems.
- Effective Cutting Width
- 1600 – 3000 mm (customisable)
- Cutting Length
- Theoretically unlimited (rolling table)
- Cutting Tools
- Vibration knife ×2, trailing knife, half-cut, pneumatic knife, press wheel, V-slot knife
- Safety Devices
- Physical anti-collision + infrared + smart beam avoidance
- Cutting Thickness
- 0.2 – 60 mm (customisable)
- Cutting Speed
- ≤ 1200 mm/s
- Cutting Accuracy
- ±0.1 mm
- Repeatability
- ≤ 0.05 mm
- Min. Cutting Diameter
- ≥ 3 mm
- Positioning
- Laser light or CCD camera positioning
- Material Fixing
- Vacuum suction
- Transmission Interface
- Ethernet port
- Software Compatibility
- AI, CAD, CorelDRAW & all box-type design software
- Command System
- DXF, HPGL compatible
- Control Panel
- Multilingual LCD touch panel
- Power Supply
- AC 220V / 380V ±10%, 50Hz — 9 kW total
- Air Pump
- 7.5 kW
- Operating Environment
- -10°C – 40°C, 20 – 80% RH
