DN8 Series
Customisable All-Purpose Cutting Machine
Fully customisable dimensions and cutter combinations for demanding production lines.
High-precision helical-rack transmission with fully customisable dimensions. Cutter heads combine freely — every function is modular. Whether cutting fabric, leather, carpet, PVC, corrugated board, foam, advertising media, carbon fibre or gaskets, the DN8 adapts to your workflow.
- Fully custom dimensions
- Freely combinable cutter heads
- Modular design — any configuration
- Built for demanding industrial lines
Technical Data
Full specifications.
Every AgileBull machine ships with a modular tooling head, servo-driven precision axes and dual-layer safety systems.
- Effective Cutting Area
- Fully customisable to spec
- Cutter Combination
- Free multi-head configuration
- Cutting Tools
- Vibration knife, trailing knife, half-cut, pneumatic knife, flying knife, press wheel, V-slot knife, milling cutter
- Safety Devices
- Physical anti-collision + infrared sensing
- Cutting Thickness
- 0.2 – 60 mm (customisable)
- Cutting Speed
- ≤ 1200 mm/s
- Cutting Accuracy
- ±0.1 mm
- Repeatability
- ≤ 0.05 mm
- Min. Cutting Diameter
- ≥ 3 mm
- Positioning
- Laser light or CCD camera positioning
- Material Fixing
- Vacuum suction
- Transmission Interface
- Ethernet port
- Software Compatibility
- AI, CAD, CorelDRAW & all box-type design software
- Command System
- DXF, HPGL compatible
- Control Panel
- Multilingual LCD touch panel
- Power Supply
- AC 220V / 380V ±10%, 50Hz — 9 kW total
- Air Pump
- 7.5 kW
- Operating Environment
- -10°C – 40°C, 20 – 80% RH
Industry Applications
Built for these industries.
Gallery
